performance parameter
| Total weight | 22000kg |
|---|---|
| Volume of Bucket | 1.4m3 |
| Engine power | 169KW |
| Swing speed | 9.4rpm |
| Travel speed | 5.7/3.1km/hr |
| Ground pressure | 0.59kg/cm2 |
| Gradeability | 26i |
| Digging force | 158.8KN |
| Total width | 3200mm |
| Shipping length | 10055mm |
| Total height of transport boom | 3697mm |
| Cab height | 3000mm |
| Turning radius at the end of the platform | 3188mm |
| Ground clearance | 506mm |
| Counterweight ground clearance | 1150mm |
| Gauge | 4039mm |
| Total width | 3199mm |
| Total length of running gear | 4940mm |
| The total width of the crawler undercarriage | 3200mm |
| Shaft diameter | 4039mm |
| Track shoe width | 600mm |
| Max digging depth | 7162mm |
| Max vertical digging depth | 4842mm |
| Max digging height | 9975mm |
| Max loading height | 7204mm |
| Max dig radius distance | 10175mm |
| Min radius of swing | 4016mm |
