performance parameter
| Total weight | 37800kg |
|---|---|
| Volume of Bucket | 1.70m3 |
| Engine power | 212KW |
| Swing speed | 8.2rpm |
| Travel speed | 4.95/3.02km/hr |
| Ground pressure | 0.69kg/cm² |
| Gradeability | 20i |
| Digging force | 196.5KN |
| Total width | 3350mm |
| Shipping length | 11310mm |
| Total height of transport boom | 3560mm |
| Cab height | 3170mm |
| Turning radius at the end of the platform | 3500mm |
| Ground clearance | 540mm |
| Counterweight ground clearance | 1270mm |
| Gauge | 2600mm |
| Total width | 2990mm |
| Total length of running gear | 5215mm |
| The total width of the crawler undercarriage | 3300mm |
| Shaft diameter | 4250mm |
| Track shoe width | 600mm |
| Max digging depth | 7550mm |
| Max vertical digging depth | 4620mm |
| Max digging height | 10380mm |
| Max loading height | 7385mm |
| Max dig radius distance | 11192mm |
| Min radius of swing | 4501mm |
