performance parameter
| Total weight | 52500kg |
|---|---|
| Volume of Bucket | 3.20m3 |
| Engine power | 298KW |
| Swing speed | 9.0rpm |
| Travel speed | 5.3/3.1km/hr |
| Ground pressure | 0.93kg/cm2 |
| Gradeability | 16i |
| Digging force | 248.5KN |
| Total width | 3900mm |
| Shipping length | 12310mm |
| Total height of transport boom | 3860mm |
| Cab height | 3372mm |
| Turning radius at the end of the platform | 3800mm |
| Ground clearance | 725mm |
| Counterweight ground clearance | 1425mm |
| gauge | 3250mm |
| Total width | 2990 mm |
| Total length of running gear | 5504mm |
| The total width of the crawler undercarriage | 3340*3900mm |
| Shaft diameter | 4470mm |
| Track shoe width | 600mm |
| Max digging depth | 7312mm |
| Max vertical digging depth | 2955mm |
| Max digging height | 10880mm |
| Max loading height | 7750mm |
| Max dig radius distance | 11716mm |
| Min radius of swing | 5235mm |
